| Tech Spec |
|
| |
|
| |
|
|
Panel |
|
| |
|
|
Screen Size
|
55”
|
Panel Technology
|
IPS
|
Native Resolution
|
3,840 × 2,160 (UHD)
|
Brightness (Typ.)
|
400 nit
|
Contrast Ratio
|
1,300:1
|
Dynamic CR
|
1,000,000 : 1
|
Color gamut
|
DCI 80 %
|
Viewing Angle (H x V)
|
178 × 178
|
Color Depth
|
10bit, 1.07Billon colors
|
Response Time
|
8ms (G to G)
|
Surface Treatment
|
3%
|
Operation Hours (Hours / Days)
|
16 / 7
|
Portrait / Landscape
|
Yes / Yes
|
| |
|
| |
|
| |
|
|
Mechanical Specification |
|
| |
|
|
Bezel Color
|
Ashed Blue
|
Bezel Width
|
Off : 6.9/6.9/6.9/18.4, On : 12.8/12.8/12.8/19.9
|
Weight (Head)
|
14.0 kg
|
Monitor Dimensions (W × H × D)
|
1,235 x 715 x 57.5 mm
|
Carton Dimensions (W × H × D)
|
1,360 x 810 x 162 mm (Box outer size)
|
Handle
|
No
|
VESA™ Standard Mount Interface
|
300 × 300 mm
|
| |
|
| |
|
| |
|
|
Connectivity |
|
| |
|
|
Input
|
HDMI (3, HDCP 2.2 / 1.4), USB 2.0 Type A (2)
|
Output
|
Audio
|
External Control
|
RS232C In / Out (4 Pin Phone Jack), RJ45 (LAN) In
|
| |
|
| |
|
| |
|
|
Environment Conditions |
|
| |
|
|
Operation Temperature
|
0 °C to 40 °C (Portrait Scene : 0 °C to 35 °C)
|
Operation Humidity
|
10 % to 80 %
|
| |
|
| |
|
| |
|
|
Power |
|
| |
|
|
Power Supply
|
AC 100-240V~, 50/60Hz
|
Power Type
|
Built-In Power
|
| |
|
| |
|
| |
|
|
Power Consumption |
|
| |
|
|
Typ./Max.
|
105 W / 160 W
|
BTU (British Thermal Unit)
|
358 BTU/Hr(Typ.), 546 BTU/Hr(Max.)
|
| |
|
| |
|
| |
|
|
Certification |
|
| |
|
|
Safety
|
CB
|
EMC
|
FCC Class "A" / CE
|
ErP
|
Yes (OldErP for Jordan)
|
| |
|
| |
|
| |
|
|
Software Compatibility |
|
| |
|
|
SuperSign CMS
|
Yes
|
SuperSign Control / Control+
|
Yes
|
SuperSign WB
|
Yes
|
SuperSign Media Editor
|
Yes
|
LG ConnectedCare
|
Yes
|
Promota
|
Yes (Not available for EU/CIS)
|
| |
|
| |
|
| |
|
|
Sound |
|
| |
|
|
Speaker
|
Yes
|
| |
|
| |
|
| |
|
|
Accessory |
|
| |
|
|
Basic
|
Remote Controller(include battery 2ea), Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder
|
