| Power supply: 4 x 1.5 V DC AA batteries (not included) |
| Power consumption: up to 16 mA |
| Display: 4 x 16 character LCD screen, 61.6 x 25.2 mm |
| Designed for: STP/UTP twin twisted, coaxial & telephone cable |
| Working ambient temperature: -10 ... + 60°C |
| Tester port: tester RJ45 master port (M), tester LOOPBACK RJ45 port (L), far-end recognizer RJ45 port (R) |
| Max cable length: up to 1350 m |
| Calibration accuracy: 3% (+/- 0.5 m) |
| Calibration cable length: > 5 m |
| Cable problems detected: open circuit, short circuit, reverse connection, crossover or cross-talk interference |
| Automatic shut-down: after 30 minutes |
| Dimensions: 180 x 80 x 40 mm |
| Net weight: 0.25 kg |
